Brake Pad Part No: 150-12270K

Street Performance / Racing Pads

Pad#: 4908
Compound: Purple
Prod #: 150-12270K
Price: $53.86
Purple
Purple Brake Pads and Box
Picture shown is for illustrative purposes only
Pad Dimensions
Thickness(in) .31
Area(in²) 1.83
Volume(in³) 0.34
Bedded N
UPC Number
UPC 889545033106
Dust & Noise Ratings
Dust Production Rating N-A
Pad Noise Rating N-A
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov

Purple Compound

Pad Characteristics

  • Composite metallic compound for high-temperature durability on aluminum and other low conductive alloy rotors.
  • Long wear rates and high-fade resistance in sustained heat.

Pad Applications

  • Sprint cars

Rotor Material

  • Aluminum
  • Steel
  • Stainless Steel
Purple Performance Stats Purple Performance Stats Zoom Image
Purple Friction Coefficient and Temperature Values Purple Friction Coefficient and Temperature Values Zoom Image

The above friction data (μ) was recorded through braking cycles from 95 mph to 40 mph at a 0.5g deceleration. Snubs were consecutively done until rotor temperature reached 1300°F. This graph represents average data and is for general trend visualisations only comparing Wilwood pads. Chart data should not be used in comparison with other manufacturer's data. Test conditions, variables, and environment can affect test results.

Temperature range and overall friction value are the primary considerations for pad selection. The pads must maintain the proper amount of friction for stopping power within the temperatures that will be realized on the track. Overall wear rate must also be considered. For most asphalt and road race applications, compounds in the high-temperature range over 1000°F are usually necessary. Dirt track, drag race, and street performance applications usually operate at temperatures between 500° and 1000°F. Keep in mind that these are general ranges and not absolute values. Many factors and unforeseen influences can affect brake temperatures. The best indicator for pad selection will always be on-track performance. If pad fade (friction loss) due to overheating occurs, improved cooling, a heavier rotor, or a higher temperature range pad may become necessary.

Wilwood Compatible Caliper(s) for Pad #4908

GP200 Caliper
Caliper Dimensions
Piston Count 2
Piston Area Range (in²) 1.23
Pad Area Range (in²) 1.83
Pad Volume Range (in³) 0.34
Max Rotor Widths (in) 0.25
Max Rotor Diameters (in) 11.00

GP200 Caliper Calipers

The GP 200 billet caliper represents the newest lightweight (only .90 pounds) caliper specifically designed for tight fit applications while utilizing a standard 2.38” lug mount. Now available (depending on part number) in either 1/8-27 NPT or a 3/8-24 fluid inlets. The GP 200 combines superior strength with a type III hard anodized finish along with several new performance features. The strength of the GP 200 is a combination of process and design. GP 200 calipers are fully CNC machined from premium grade alloy billet. The FEA generated body design incorporates a highly fortified transition between the piston housings and the bridges. Strengthening this critical area of the caliper has substantially increased its resistance to deflection and body separation under load. View GP200 Caliper Calipers
GP200 Caliper
Caliper Dimensions
Piston Count 2
Piston Area Range (in²) 1.23
Pad Area Range (in²) 1.83
Pad Volume Range (in³) 0.34
Max Rotor Widths (in) 0.25
Max Rotor Diameters (in) 11.00

GP200 Caliper Calipers

The GP 200 billet caliper represents the newest lightweight (only .90 pounds) caliper specifically designed for tight fit applications while utilizing a standard 2.38” lug mount. Now available (depending on part number) in either 1/8-27 NPT or a 3/8-24 fluid inlets. The GP 200 combines superior strength with a type III hard anodized finish along with several new performance features. The strength of the GP 200 is a combination of process and design. GP 200 calipers are fully CNC machined from premium grade alloy billet. The FEA generated body design incorporates a highly fortified transition between the piston housings and the bridges. Strengthening this critical area of the caliper has substantially increased its resistance to deflection and body separation under load. View GP200 Caliper Calipers
GP200 Caliper
Caliper Dimensions
Piston Count 2
Piston Area Range (in²) 1.23
Pad Area Range (in²) 1.83
Pad Volume Range (in³) 0.34
Max Rotor Widths (in) 0.25
Max Rotor Diameters (in) 11.00

GP200 Caliper Calipers

The new GP 200A billet caliper represents the lightest (only .90 pounds) caliper specifically designed for tight fit applications while utilizing a standard 2.38” lug mount. Now available (depending on part number) in either 1/8-27 NPT or a 3/8-24 fluid inlets. The GP 200A combines superior strength with a type III hard anodized finish along with several new performance features. The strength of the GP 200A is a combination of process and design. GP 200A calipers are fully CNC machined from premium grade alloy billet. The FEA generated body design incorporates a highly fortified transition between the piston housings and the bridges. Strengthening this critical area of the caliper has substantially increased its resistance to deflection and body separation under load. View GP200 Caliper Calipers
